Pipe Inspection Cameras

My Image

Tracer Electronics offers a complete line of professional inspection camera systems, ranging from small 1" to large 12" pipe. We also provide small reel systems, e.g., 100-150' that affordable to anyone wanting a camera system, and larger systems, e.g., 200-400' that are perfect for high volume inspectors such as plumbers and municipalities.

  • Standard Push Camera (100ft - 400ft)

    vCam-6 HD

    The vCam-6 HD professional pipe inspection system features a High Definition (1080p) camera head and a 9.7" high definition (1024 x 768) LCD. In addition to "Best in Class" performance, a 1TD hard drive for high capacity video storage and Wi-Fi with FREE iOS/Android app.

    Other features include:

    • Built-In Li-Ion rechargeable battery.
    • Real-time zoom.
    • One-button JPEG capture.
    • Built-in camera test port.
    • Fully locatable push rod.
    • Complete on-screen instructions only one button touch away.

    Available lengths: 200ft / 300ft / 400ft

    Available camera: 1.3" / 1.8"

  • Mini Camera System (1-1/2” pipe and up)

    vCamDrain

    The vCamDrain inspection camera system is a wireless Wi-Fi reel controlled by an iOS or Android app. The vCam Mobile Controller (VMC) app manages all the reel functions, including the camera head LEDs and the 512Hz/640Hz/33kHz locating sonde, and the distance counter. In addition, the VMC app displays the reel's Wi-Fi status, battery level, and even charging status. The system's Li-Ion battery is capable of up to 10-hour operation on a full charge.

    The
    vCamDrain features robust stainless-steel HD cameras with a sapphire lens, and ultra-bright LEDs, producing a crisp, clear image of the pipe interior. The 9mm ultra-flex pushrod provides flexibility and push strength, and its unique smooth exterior allows it to navigate multiple bends, tighter turns, P-traps, and toilet traps. The vCamDrain is perfect for drain lines as small as 1.5" in diameter. Two camera heads available are 18mm fixed and 20mm self-leveling. All camera, spring, and sonde assemblies are field changeable.


    vCamMX-2

    The vCamMX-2 mini pipe inspection system is a compact all-in-one, extremely lightweight inspection camera at an affordable price. Available in two lengths of pushrod (100ft or 150ft) and with two interchangeable SD color camera heads (0.7” fixed or 1” self-leveling) can inspect lines from 1-3/4” up to 4”. The vCamMX mini camera has all the features of the larger camera systems such as dual-frequency locatable sonde, traceable pushrod, distance counter, internal rechargeable battery, and built-in microphone for voice-over. The MX reels feature stainless steel tubular construction with a lightweight, rugged carbon fiber pushrod drum.

    Available lengths: 100ft / 150ft / 200ft

    Available camera: 0.7" / 1.0"


    Boring Inspection Camera System

    The vCamMX professional video camera system for bore inspections utilizes the 1" diameter self-leveling color camera head, 100' or 150' reel (10mm locatable rod), and necessary items to quickly inspect bores before installing gas pipe. The vCamMX provides a required level of inspection to prevent any chance of sewer cross boring. It's quick, easy, and affordable.

    Other features include a Built-In Li-Ion rechargeable battery, real-time zoom, one-button JPEG capture, and fully locatable push rod, carbon fiber reel, and more.

  • Camera/Sonde Locators

    vLoc3-Cam (graphical sonde mode)

    The vLoc3-Cam receiver is designed primarily for locating sondes (most frequencies). Users can also use passive and radio modes to find signals radiating from adjacent pipes and cables. These passive modes provide the ability to sweep an area for both known and unknown utilities. The active mode (83 kHz) allows users to locate the entire pushrod length using an optional transmitter.


    vScan & vScan-M (sonde mode)

    The vScan receiver is a fully-featured sonde & camera locator. It offers the push-button depth, line compass, 512Hz & 33kHz sonde frequencies, power 60, Radio mode, and much more.


    VM-540

    The VM-540 is our most affordable sonde locator. Perfect for anyone on a tight budget. While features and pricing are minimal, performance is excellent.

Video Pipe Inspection Camera Systems
